ConnectUC (IP & Ports)
70.42.44.0/24
75.98.50.0/24
TCP - 443, 9002 (Encrypted Web Socket Traffic)
UDP - 443, 30000-40000 (Audio communications over DTLS, which is TLS for UDP)
ReachUC (IP & Ports)
70.42.44.0/24
75.98.50.0/24
TCP Port 6050
TCP UDP 5060
UDP 17000 to 37999
FAQ
How does ConnectUC Encrypt / Secure traffic?
All traffic between ConnectUC and the back-end services is encrypted. All signaling is sent and received over encrypted WebSockets (SSL/TLS).
Voice traffic is encrypted with DTLS (TLS for UDP).
What firewall ports need to be open outbound for ConnectUC?
ConnectUC uses encrypted WebSocket connections on ports 443 tcp/udp and 9002 tcp. Additionally audio communications is over DTLS (TLS for UDP) on ports 30000 - 40000 udp.
Chat additionally opens a port 443 to Amazon Chime messaging services. WebSocket URLs connect to servers in the DNS domain ws-messaging.chime.aws
Calling doesn't seem to work; what could be wrong?
ConnectUC utilizes a websocket on port 9002 to initiate communications. The user may have some filtering application on their computer or a firewall that might be blocking port 9002 tcp outbound.
If port 9002 is blocked the user will see a yellow warning banner.
